Chapter 1: AC701 Evaluation Board Features
The TPS84K and LMZ22000 family adjustable voltage regulators have their output voltage
set by an external resistor. The regulator topology on the AC701 board permits the
UCD90120A to monitor rail voltage and current. Voltage margining at +5% and -5% is also
implemented.
Each voltage regulator's external V
the regulator is standalone. The UCD90120A has two ADC inputs allocated per voltage
rail, one input for the remote voltage sense connection, the other for the current sense
resistor op amp output voltage connection. The UCD90120A ADC full scale input is 2.5V.
The remote voltage feedback is scaled to approximately 2V if it exceeds 2V—that is, the
VCCO_VADJ rail for the 2.5V and 3.3V modes, and the FPGA_3V3 rail also at 3.3V are
resistor attenuated to scale the remotely sensed voltage at 0.606 to give approximately 2V
at the ADC input pin for a 3.3V remote sense value. Rails below 2V are not scaled.
Each rail's current sense op amp has its gain set to provide approximately 2V max at the TI
UCD90120A ADC input pin when the rail current is at its expected maximum current
level, as shown in
The UCD90120A has an assignable group of GPIO pins with PWM capability. Each
controller channel has a PWM GPIO pin connected to the associated voltage regulator
V
is configured in 3-state mode. This pin is not driven unless a Margin command is executed.
The Margin command is available within the TI Fusion Digital Power designer software.
During the margin high or low operation, the PWM GPIO pin drives a voltage into the
voltage regulator V
V

XADC Power System Measurement

The AC701 board XADC interface includes power system voltage and current measuring
capability. The VCCINT, VCCAUX and VCCBRAM rail voltages are measured via the
XADC internal voltage measurement capability. Other rails are measured via two external
Analog Devices ADG707BRU multiplexers U14 and U13. Each rail has a TI INA333 op amp
strapped across its series current sense resistor Kelvin terminals. This op amp has its gain
adjusted to give approximately 1V at the expected full scale current value for the rail.
66
Figure 1-41
pin. The external V
ADJ OUT
pin, which causes a slight voltage change resulting in the regulator
ADJ
moving to the margin +5% or -5% voltage commanded.
OUT
www.xilinx.com
setting resistor is calculated and implemented as if
OUT
(U8 controller #1) and Figure 1-42
setting resistor is also wired to this pin. The PWM GPIO pin
(U9 controller #2).
