  • Page 1 AC701 Si5324 Design November 2014 XTP231...

  • Page 2: Revision History

    NOTICE OF DISCLAIMER: The information disclosed to you hereunder (the “Information”) is provided “AS-IS” with no warranty of any kind, express or implied. Xilinx does not assume any liability arising from your use of the Information. You are responsible for obtaining any rights you may require for your use of this Information.
  • Page 3 Overview Xilinx AC701 Board Software Requirements AC701 Setup Reducing Jitter with the Si5324 Compile AC701 Si5324 Design References Note: This presentation applies to the AC701...
  • Page 4 Bypass mode or in PLL mode. Neither the Evaluation board nor the design are for characterization purposes. Please see the Silicon Labs web site for Jitter Attenuator device data. Reference Design Source – AC701 Si5324 Design Files (2014.4 C) ZIP file – Available through http://www.xilinx.com/ac701 Note: Presentation applies to the AC701...
  • Page 5 Xilinx AC701 Board...

  • Page 6: Vivado Software Requirements

    Vivado Software Requirements Xilinx Vivado Design Suite 2014.4, Design Edition Note: Presentation applies to the AC701...
  • Page 7 AC701 Setup Connect a USB Type-A to Micro-B cable to the USB JTAG (Digilent) connector on the AC701 board – Connect this cable to your PC – Power on the AC701 board...
  • Page 8 AC701 Si5324 Setup Unzip the AC701 Si5324 Design Files (2014.4 C) ZIP file – Available through http://www.xilinx.com/ac701 Note: Presentation applies to the AC701...
  • Page 9 Reducing Jitter with the Si5324...
  • Page 10 Reducing Jitter with the Si5324 A means of measuring jitter is required for this section A LeCroy 816Zi-A Scope was used (stock photo shown) Note: Presentation applies to the AC701...
  • Page 11 Reducing Jitter with the Si5324 Connect SMA cables to J33 and J34, USER_GPIO_P/N Connect these cable to your oscilloscope...
  • Page 12 Reducing Jitter with the Si5324 Open a Vivado Tcl Shell: Start → All Programs → Xilinx Design Tools → Vivado 2014.4 → Vivado 2014.4 Tcl Shell Note: Presentation applies to the AC701...
  • Page 13 Reducing Jitter with the Si5324 Download the “bypass” bitstream with Vivado In the Vivado Tcl Shell type: cd C:/ac701_si5324/ready_for_download source bypass_download.tcl Note: Presentation applies to the AC701...
  • Page 14 Reducing Jitter with the Si5324 LeCroy Oscilloscope setup Press the Default Setup followed by the Auto Setup twice...
  • Page 15 Reducing Jitter with the Si5324 Adjust the Horizontal knob until you have 5 μs/div...
  • Page 16 Reducing Jitter with the Si5324 From the LeCroy scope menu, select Analysis → Serial Data…...
  • Page 17 Reducing Jitter with the Si5324 Select “Quick View”...
  • Page 18 Reducing Jitter with the Si5324 Set the inputs to Input1-Input2 and the Data to match your setup and click OK...
  • Page 19 Reducing Jitter with the Si5324 Click the Close button...
  • Page 20 Reducing Jitter with the Si5324 Note that the DCD (Duty Cycle Distortion) is 53.6 ps...
  • Page 21 Reducing Jitter with the Si5324 Download the “enabled” bitstream with Vivado In the Vivado Tcl Shell type: source enabled_download.tcl Note: Presentation applies to the AC701...
  • Page 22 Reducing Jitter with the Si5324 Note that the DCD (Duty Cycle Distortion) is 4.0 ps – Including the Si5324 Jitter Attenuator PLL in the clock path, reduces DCD...
  • Page 23 Compile AC701 Si5324 Design...
  • Page 24 Compile AC701 Si5324 Design Open Vivado Start → All Programs → Xilinx Design Tools → Vivado 2014.4 → Vivado Select Open Project Note: Presentation applies to the AC701...
  • Page 25 Compile AC701 Si5324 Design Open the AC701 Design: – <Design Name>\ac701_si5324.xpr Note: Presentation applies to the AC701...
  • Page 26 Compile AC701 Si5324 Design The design is fully implemented; you can recompile, or export to SDK – To recompile, right-click synth_1, select Reset Runs then Generate Bitstream Note: Presentation applies to the AC701...
  • Page 27 Compile AC701 Si5324 Design Once done, both the Synthesis and Implementation will have green check marks Note: Presentation applies to the AC701...
  • Page 28 Compile AC701 Si5324 Design The BIST Design has been implemented with IP Integrator (IPI) Click Open Block Design Note: Presentation applies to the AC701...
  • Page 29 Compile AC701 Si5324 Design All the IP Blocks used in the design can be seen in this view Click Open Implemented Design Note: Presentation applies to the AC701...
  • Page 30 Compile AC701 Si5324 Design View Implemented Design Note: Presentation applies to the AC701...
  • Page 31 Compile AC701 Si5324 Design Select File → Export → Export Hardware Click OK Note: Presentation applies to the AC701...
  • Page 32 Compile AC701 Si5324 Design Select File → Launch SDK Click OK Note: Presentation applies to the AC701...
  • Page 33 Compile AC701 Software in SDK SDK Software Compile - Build ELF files in SDK Note: Presentation applies to the AC701...
  • Page 34 Program AC701 with Si5324 Design...
  • Page 35 Init memory with the Si5324 Application ELF – Update the bitstream (download.bit) with the Si5324 Application ELF – Cycle power on the AC701 to clear out any previous settings in the Si5324 – Select Xilinx Tools → Program FPGA (1) Note: Presentation applies to the AC701...
  • Page 36 Program AC701 with Si5324 Design Init memory with the Si5324 Application ELF – Select hello_iic_5324.elf (1) – Click Program Note: Presentation applies to the AC701...
  • Page 37 Program AC701 with Si5324 Design Note that the DCD (Duty Cycle Distortion) has a low value now...
  • Page 38 Program AC701 with Si5324 Design To set the Si5324 for Bypass mode edit the hello_iic_si5324.c Locate the line: // Change to 1 to set Si5324 into Bypass PLL mode Change the #if 0 to #if 1 Note: Presentation applies to the AC701...
  • Page 39 Program AC701 with Si5324 Design To set the Si5324 for Bypass mode edit the hello_iic_si5324.c Scroll down and locate the line: // Change to 1 to set Si5324 Loop Bandwidth (BWSEL) Change the #if 1 to #if 0 Note: Presentation applies to the AC701...
  • Page 40 Program AC701 with Si5324 Design Recompile the ELF file – Select the hello_iic_5324 project and press F5 to rebuild Note: Presentation applies to the AC701...
  • Page 41 Init memory with the Si5324 Application ELF – Update the bitstream (download.bit) with the Si5324 Application ELF – Cycle power on the AC701 to clear out any previous settings in the Si5324 – Select Xilinx Tools → Program FPGA (1) Note: Presentation applies to the AC701...
  • Page 42 Program AC701 with Si5324 Design Init memory with the Si5324 Application ELF – Select hello_iic_5324.elf (1) – Click Program Note: Presentation applies to the AC701...
  • Page 43 Program AC701 with Si5324 Design Note that the DCD (Duty Cycle Distortion) is now higher...
  • Page 44 References...
  • Page 45 References Silicon Labs – SI5324 Data Sheet • http://www.silabs.com/Support%20Documents/TechnicalDocs/Si5324.pdf Vivado Programming and Debugging – Vivado Design Suite Programming and Debugging User Guide – UG908 • http://www.xilinx.com/support/documentation/sw_manuals/xilinx2014_4/ ug908-vivado-programming-debugging.pdf...
  • Page 46 Documentation...
