AC701 Built-In Self Test
Flash Application
October 2012
XTP194

Advertisement

loading

Related Manuals for Xilinx AC701

Summary of Contents for Xilinx AC701

  • Page 1 AC701 Built-In Self Test Flash Application October 2012 XTP194...

  • Page 2: Revision History

    NOTICE OF DISCLAIMER: The information disclosed to you hereunder (the “Information”) is provided “AS-IS” with no warranty of any kind, express or implied. Xilinx does not assume any liability arising from your use of the Information. You are responsible for obtaining any rights you may require for your use of this Information.
  • Page 3 Overview Xilinx AC701 Board Software Requirements AC701 Setup AC701 BIST (Built-In Self Test) References Note: This presentation applies to the AC701...
  • Page 4 • Embedded System Tools Reference Guide (UG111) • http://www.xilinx.com/ise/embedded/edk_ip.htm Reference Design Source – rdf0220.zip – Available through http://www.xilinx.com/ac701 Note: Presentation applies to the AC701...
  • Page 5 Xilinx AC701 Board Note: Presentation applies to the AC701...

  • Page 6: Vivado Software Requirements

    Vivado Software Requirements Xilinx Vivado 2012.3 software Note: Presentation applies to the AC701...
  • Page 7 EDK Software Requirement Xilinx EDK 14.3 software Note: Presentation applies to the AC701...
  • Page 8 SDK Software Requirement Xilinx SDK 14.3 software Note: Presentation applies to the AC701...
  • Page 9 AC701 Setup Connect a USB Type-A to Micro-B cable to the USB JTAG (Digilent) connector on the AC701 board – Connect this cable to your PC...
  • Page 10 AC701 Setup Connect a USB Type-A to Mini-B cable to the USB UART connector on the AC701 board – Connect this cable to your PC – Power on the AC701 board for UART Drivers Installation...
  • Page 11 AC701 Setup Install USB UART Drivers – CP210x_VCP_Win_XP_S2K3_Vista_7.exe Note: Presentation applies to the AC701...
  • Page 12 AC701 Setup Reboot your PC if necessary Right-click on My Computer and select Properties – Select the Hardware tab – Click on Device Manager Note: Presentation applies to the AC701...
  • Page 13 AC701 Setup Expand the Ports Hardware – Right-click on Silicon Labs CP210x USB to UART Bridge and select Properties Note: Presentation applies to the AC701...
  • Page 14 AC701 Setup Under Port Settings tab – Click Advanced – Set the COM Port to an open Com Port setting from COM1 to COM4 Note: Presentation applies to the AC701...
  • Page 15 AC701 BIST Setup Board Power must be on before starting Tera Term Start the Terminal Program – Select your USB Com Port – Set the baud to 9600 Note: Presentation applies to the AC701...
  • Page 16 Creating the AC701 BIST Design Unzip the AC701 BIST Design Files (2012.3 CES) – Available through http://www.xilinx.com/ac701 Note: Presentation applies to the AC701...
  • Page 17 AC701 BIST Open a ISE Design Suite Command Prompt and type: cd C:\ac701_bist\ready_for_download ac701_bist.bat Note: Presentation applies to the AC701...
  • Page 18 AC701 BIST View initial BIST screen Note: Presentation applies to the AC701...
  • Page 19 AC701 BIST UART Test – Type “1” to start the UART Test – After each test, press any key to return to the main menu Note: Presentation applies to the AC701...
  • Page 20 AC701 BIST LED Test – Type 2 to begin LED Test View Walking 1’s pattern on GPIO LEDs – Sequence repeats twice Note: Presentation applies to the AC701...
  • Page 21 AC701 BIST IIC Test – Type 3 to begin IIC Test Note: Presentation applies to the AC701...
  • Page 22 AC701 BIST Timer Test – Type 4 to begin Timer Test Note: Presentation applies to the AC701...
  • Page 23 AC701 BIST Rotary Test – Type 5 to begin Rotary Test – Turn the rotary switch (under the LCD) back and forth Note: Presentation applies to the AC701...
  • Page 24 AC701 BIST GPIO Switch Test – Set 4-position GPIO DIP Switch (SW4) – Type 6 to begin GPIO Switch Test • Reads switch settings Note: Presentation applies to the AC701...
  • Page 25 AC701 BIST LCD Test – Type 7 to begin LCD Test Note: Presentation applies to the AC701...
  • Page 26 AC701 BIST External Memory Test – Type 8 to begin External Memory Test Note: Presentation applies to the AC701...
  • Page 27 AC701 BIST Internal Memory Test – Type 9 to begin BRAM Memory Test Note: Presentation applies to the AC701...
  • Page 28 AC701 BIST Ethernet Test – Type A to begin Ethernet Test Note: Presentation applies to the AC701...
  • Page 29 AC701 BIST Button Test – Type C to begin Button Test Note: Presentation applies to the AC701...
  • Page 30 References...
  • Page 31 References EDK Documentation – Embedded System Tools Reference Guide • http://www.xilinx.com/support/documentation/sw_manuals/xilinx14_3/est_rm.pdf 7 Series Configuration – 7 Series FPGAs Configuration User Guide • http://www.xilinx.com/support/documentation/user_guides/ ug470_7Series_Config.pdf...
  • Page 32 Documentation...
  • Page 33 Documentation Artix-7 – Artix-7 FPGA Family • http://www.xilinx.com/products/silicon-devices/fpga/artix-7/index.htm AC701 Documentation – Artix-7 FPGA AC701 Evaluation Kit • http://www.xilinx.com/products/boards-and-kits/EK-A7-AC701-G.htm – AC701 User Guide • http://www.xilinx.com/support/documentation/boards_and_kits/artix-7/ ac701_ug/v1_0/ug952-ac701-a7-eval-bd.pdf...
