AC701 Evaluation Board Features

Overview

The AC701 evaluation board for the Artix®-7 FPGA provides a hardware environment for
developing and evaluating designs targeting the Artix-7 XC7A200T-2FBG676C FPGA. The
AC701 board provides features common to many embedded processing systems,
including a DDR3 SODIMM memory, an 4-lane PCI Express® interface, a tri-mode
Ethernet PHY, general purpose I/O, and a UART interface. Other features can be added by
using mezzanine cards attached to the VITA-57 FPGA mezzanine connector (FMC)
provided on the board. A high pin count (HPC) FMC connector is provided. See
Board Features
Feature Descriptions, page

Additional Information

See
relevant to the AC701 board.

AC701 Board Features

•
•
•
•
•
•
•
•
AC701 Evaluation Board
UG952 (v1.2) August 28, 2013
for a complete list of features. The details for each feature are described in
8.
Appendix F, Additional Resources
Artix-7 XC7A200T-2FBG676C FPGA
1 GB DDR3 memory SODIMM
256 Mb Quad-SPI Flash memory
Secure Digital (SD) connector
USB JTAG via Digilent module
Clock Generation
• Fixed 200 MHz LVDS oscillator
2
• I C programmable LVDS oscillator
• SMA connectors
• SMA connectors for GTP transceiver clocking
GTP transceivers
• FMC HPC connector (two GTP transceivers)
• SMA connectors (one pair each for TX, RX and REFCLK)
• PCI Express (four lanes)
• Small form-factor pluggable plus (SFP+) connector
• Ethernet PHY RGMII interface (RJ-45 connector)
PCI Express endpoint connectivity
