7. LW3 Programmers' Reference
7.4. System Commands
7.4.1. Setting the Device Label

INFO: The device label can be changed to a custom text in the
Command and Response #devicelabel
SET·/MANAGEMENT/UID/DeviceLabel=<custom_name>
ç
pw·/MANAGEMENT/UID/DeviceLabel=<custom_name>
æ
The Device Label can be 39 character length and ASCII characters are allowed. Longer names are truncated.
Example
ç SET /MANAGEMENT/UID.DeviceLabel=4x2_Conference1
æ pw /MANAGEMENT/UID.DeviceLabel=4x2_Conference1
7.4.2. Resetting the Device
The receiver can be restarted – the current connections (LAN, RS-232, USB) will be terminated.
Command and Response #reboot #restart
ç CALL·/SYS:reset()
æ mO·/SYS:reset=
Example
ç CALL /SYS:reset()
æ mO /SYS:reset=
7.4.3. Restore the Factory Default Settings
Command and Response
ç CALL·/SYS:factoryDefaults()
æ mO·/SYS:factoryDefaults=
Example
ç CALL /SYS:factoryDefaults()
æ mO /SYS:factoryDefaults=
The device is restarted, current connections are terminated, and the default settings are restored. See the
complete list in the Factory Default Settings
#factory
Status tab of the LDC software.
#label
section.
Applied firmware package: v1.5.0b8 | LDC software: v2.3.0b1
MMX4x2 series – User's Manual
7.4.4. Querying the Firmware Version
Command and Response #firmwareversion
ç GET·/SYS/MB.FirmwareVersion
pr·/SYS/MB.FirmwareVersion=<firmware_version>
æ
Example
ç GET /SYS/MB.FirmwareVersion
æ pr /SYS/MB.FirmwareVersion=1.2.0b3
7.4.5. Control Lock
Enable/disable the operation of the front panel buttons.
Command and Response #lockbutton
SET·/MANAGEMENT/UI.ControlLock=<lock_status>
ç
æ pw·/MANAGEMENT/UI.ControlLock=
Parameters
Parameter Parameter description Values
<lock_status> Front panel button
locking status
Example
ç SET /MANAGEMENT/UI.ControlLock=1
æ pw /MANAGEMENT/UI.ControlLock=1
7.4.6. Identify the Device
Calling the method results the blinking of the status LEDs for 10 seconds. The feature helps to identify the
device itself in the rack shelf.
Command and Response #identifyme
ç CALL·/MANAGEMENT/UI:identifyMe()
æ mO·/MANAGEMENT/UI:identifyMe
Example
ç CALL /MANAGEMENT/UI:identifyMe()
æ mO /MANAGEMENT/UI/identifyMe
#buttonlock
<lock_status>
Value description
None: all functions of the front panel button are enabled.
0
1 The front panel buttons are locked but can be unlocked
by button combination. See the details in the
Lock section
2 The front panel buttons are locked and cannot be
unlocked by button combination, only in LDC (on the
Status tab) or using the LW3 command.
73
Control
