11. Appendix
IR and RS-232 Ports
Port name Port nr. (LW3)
Local IR input S1
Local IR output D1
* Only in case of
MMX4x2-HDMI-USB20-L model.
11.3.2. MMX4x2-HT200
Audio/Video Ports
Video port nr.
Port name
(LW2)
TPS in 1 1
HDMI in 2 2
HDMI in 3 3
HDMI in 4 4
Analog audio in -
HDMI out 1 1
HDMI out 2 2
Analog audio out -
IR and RS-232 Ports
Port name Port nr. (LW3)
Local IR input S1
Local IR output D1
TPS IR input S2
TPS IR output D2
Port name Port nr. (LW3)
Local serial port
Local serial port #2 *
Video port nr. Audio port nr. Audio port nr. (LW3)
(LW3) (LW2)
Till fw v1.1.0 From fw v1.2.0
I1 1 I1
I2 2 I2
I3 3 I3
I4 4 I4
- 5 I5
O1 1 O1
O2 2 O2
- 3 O3
Port name Port nr. (LW3)
Local serial port
TPS serial link
Applied firmware package: v1.5.0b8 | LDC software: v2.3.0b1
MMX4x2 series – User's Manual
11.4. Content of Backup File
The backup file contains numerous settings and parameters saved from the device. When the file is uploaded
to a device, the followings will be overwritten:
P1
P2
Mute status, Lock status, Switch state
Autoselect mode, Port priority
Video port name, Audio port name, HDCP setting
Port name, HDCP mode, HDMI mode, Power +5V mode
Test pattern mode, clock source, and type
A1 / A2
(depends on the Audio port name, Audio output enabled, S/PDIF mode
selected HDMI
output)
Port name, Volume, Balance, Gain
A3
O1
Port name, Volume, Balance
O2
O3
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity
Port name and CI (Command Injection) port number
P1
Port status (enable / disable), Code length, Repetition code, Enable modulation
P2
Input port name, Output port name
CI status (enable / disable), CI port number
Saved IR codes, names
DHCP status (enable / disable)
Static IP address, Network mask, Gateway address
Control lock status, Device label
User EDID data (U1-U14), Emulated EDIDs by ports
Presets (1-4)
Event manager: settings of all Events (E1-E100)
Audio / Video crosspoint settings
TPS / HDMI input ports
HDMI output ports
Analog audio input port
Analog audio output port
Local and TPS serial port
Local and TPS IR port
Network settings
Further settings
