7.4.11. View error list

Description: Shows the basic error list since last boot up.
Command {ELIST=?}
Response (ELIST#<num>●<elevel>●<code>
Legend:
Explanation: There are no errors only standard notices that occur on boot up.
Info: The error list can contain NOTICEs and WARNINGs under normal operation. These entries
do not mean that there is any problem with the matrix!
7.5.

System commands

7.5.1. Reload factory defaults

Description: Factory default settings can be reloaded for different functions separately.
Multiple functions can be entered.
Command {FACTORY=<f1>;<f2>;...;<fx>}
Response (FACTORY●<f1>...)CrLf
Legend:
IONAMES
PRESETS
IOCARDS
EDIDMEM
Section 7. Programmers reference
Format
●<param>●<occ>)CrLf
...
(ELIST#<num>●<elevel>●<code>
●<param>●<occ>)CrLf
<num>: line number
<elevel>: NOTICE =
WARNING = Possible
MATTER =
ERROR =
FATAL =
<code>: short name for type of log entry
<param>: technical parameter
<occ>: occurrence number for this type of log entry
Format
...
(FACTORY●<fx>...)CrLf
<f1>, <f2> are the names of the functions which have to be reset to factory
default. Any number of <fx> can be entered, separated by semicolons.
<fx> Restores factory settings to
Crosspoint table and configuration
XPOINT
(All outputs to in1, unmute, unlock)
Input and output names
Crosspoint presets
(All output to in1, unmuted), and preset names
All I/O settings for boards currently in the
frame
EDIDS Emulated EDIDs (F49 is default)
Clear User and Dynamic EDIDs
Restores all of the factory settings listed
ALL
above
→ {elist=?}
←
(ELIST#1 Notice BOOT
p:0x03 o:1)CrLf
...
←
(ELIST#2 Notice READY
p:0x00 o:1)CrLf
Not an error. Initialization information.
problem
normal operation.
Problem that may lead to further errors.
Serious error. Must report to support.
Fatal error. Normal
possible.
→ {factory=xpoint;iocards;edids}
← (FACTORY XPOINT...)CrLf
← (FACTORY IOCARDS...)CrLf
← (FACTORY EDIDS...)CrLf
UMX4x4-Pro
User's Manual
Example
without influencing
operation is
Example
Additional response
none
(INAME#1=Input1)
(ONAME#1=Output1)
(PNAME#1=Preset1)
(I1 ALL)
(SPR01)...(SPR32)
none
none
(DE_OK)
as above
Page 85 / 129
