6. LW2 Programmers' Reference
6.4.11. Change the Audio Input Priorities
The settings of audio input priority can be changed as follows.
Command and Response
 {PRIO_A<out>=<in1_prio>;<in2_prio>;...;<inn_prio>}
 (PRIO_A<out>=<in1_prio>;<in2_prio>;...;<inn_prio>)CrLf
Parameters
See the previous section.
Example
 {prio_a1=1;0;2}
 (PRIO_A1=1;0;2)
Input 2 has the highest priority (0), Input 1 has the second highest (1). Input 3 has the lowest priority (2).

ATTENTION! Always set all the priority of the ports when changing, otherwise, the change will not be
executed and the response will be the current setting (like querying the priority setting).

INFO: The audio priorities can be queried by typing the {prio_a<out>=?} command.
MMX4x2 series – User's Manual
6.5. Network Configuration
6.5.1. Query the Current IP Status
The IP address settings can be queried as follows.
Command and Response
 {IP_STAT=?}
 (IP_STAT=<type>;<ip_address>;<subnet_mask>;<gateway_addr>)CrLf
Parameters
<type>
<ip_addr>
<subnet_mask>
<gateway_addr>
Example
 {ip_stat=?}
 (IP_STAT=0;192.168.0.100;255.255.255.0;192.168.0.1)
The device has a static (fix) IP address: 192.168.0.100; the subnet mask is 255.255.255.0, the gateway
address is 192.168.0.1.
6.5.2. Set the IP Address
IP address can be set as follows.
Command and Response
 {IP_ADDRESS=<type>;<ip_address>}
 (IP_ADDRESS=<type>;<ip_address>)CrLf
Parameters
See the previous section.
Example
 {ip_address=0;192.168.0.110}
 (IP_ADDRESS=0;192.168.0.110)
INFO:

fix IP address that is stored in the device even if DHCP is enabled; in this case, this IP address is not valid.
Applied firmware package: v1.5.0b8 | LDC software: v2.3.0b1
Parameter Parameter description Value
Assignment of the IP address
(four decimal octets separated by dots)
IP address
(four decimal octets separated by dots)
Subnet mask
(four decimal octets separated by dots)
Gateway address
The IP address can be queried by typing the {ip_address=?} command. The response contains the
66
#dhcp #ipaddress #network
Value description
static
0
dynamic (DHCP)
1
