7. LW3 Programmers' Reference
7.6. Audio Port Settings frm Firmware v1.2.0
ATTENTION!
The audio port setting commands depend on the installed firmware version of the device. If
your device is installed with firmware v1.1.0, see the
following LW3 commands are related to firmware v1.2.0 and above. To query the firmware version of your
device, see the Querying the Firmware Version
the LW3 Command Changes in Firmware v1.2.0
INFO:
Audio port numbering can be found in the
7.6.1. Querying the Status of Source Port
Command and Response #portstatus
ç GET·/MEDIA/AUDIO/XP.SourcePortStatus
pr·/MEDIA/AUDIO/XP.SourcePortStatus=<audio_in1_state>;<audio_in2_state>;<audio_in3_state>
æ
Parameters
<audio_in#_state>: The response contains 5 ASCII characters for each port. The first character indicates the
mute/lock state, the next four characters represent a 2-byte HEX code showing the current state of the input
ports.
Example
ç GET /MEDIA/AUDIO/XP.SourcePortStatus
æ pr /MEDIA/AUDIO/XP.SourcePortStatus=T000C;T0008;M000F
Legend
Letter (Character 1)
Mute state Lock state
T Unmuted Unlocked
L Unmuted Locked
M
Muted Unlocked
U Muted Locked
Byte 1
Character 2 Character 3
BIT 7-6 BIT 5-4 BIT 3-2
Reserved Reserved Reserved
0 0
0 1
Reserved Reserved Reserved
1 0
1 1
Audio Port Settings for Firmware v1.1.0
section. You can find the complete list of the changes in
section.
Input/Output Port Numbering section.
Letter Mute / Lock status
Reserved character, always 0.
Byte 1
Reserved character, always 0.
Reserved character, always 0.
Byte 2
Signal present / Connection status
Byte 2
Character 4 Character 5
BIT 1-0 BIT 7-6 BIT 5-4 BIT 3-2
Signal present
Reserved Reserved Reserved
status
Reserved Reserved Reserved
No signal
Signal
presents
