INVT Goodrive20-EU VFD Series Operation Manual page 94

Goodrive20-EU series VFD
Function
Name
code
Acceleration/
deceleration
P10.34 time selection
of simple PLC
0 – 7 step
Acceleration/
deceleration
P10.35 time selection
of simple PLC
8 – 15 step
PLC restart
P10.36
mode
Detailed instruction of parameters
Setting range of P10.(2n, 1<n<17): -100.0 –
100.0%
Setting range of P10.(2n+1, 1<n<17): 0.0 –
6553.5s (min)
Below is the detailed instruction:
Function
Binary bit
code
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.34
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.35
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
After the users select the corresponding
acceleration/deceleration time, the combining 16
binary bit will change into decimal bit, and then
set the corresponding function codes.
Setting range: -0x0000 – 0xFFFF
0: Restart from the first stage; stop during
running (caused by the stop command, fault or
power loss), run from the first stage after restart.
1: Continue to run from the stop frequency; stop
during running (cause by stop command and
fault), the VFD will record the running time
automatically, enter into the stage after restart
and keep the remaining running at the setting
frequency.
ACC/ ACC/
Step
DEC 0 DEC 1
0 00 01
1 00 01
2 00 01
3 00 01
4 00 01
5 00 01
6 00 01
7 00 01
8 00 01
9 00 01
10 00 01
11 00 01
12 00 01
13 00 01
14 00 01
15 00 01
90
Function parameters
Default
value
ACC/ ACC/
0x0000
DEC 2 DEC 3
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
0x0000
10 11
10 11
10 11
10 11
10 11
0
Modify
○
○
◎
