Goodrive20-EU series VFD
Function
Name
code
S1 terminal
P05.14
switching on
delay time
S1 terminal
P05.15
switching off
delay time
S2 terminal
P05.16
switching on
delay time
S2 terminal
P05.17
switching off
delay time
Detailed instruction of parameters
SB1
SB2
SB3
Sln
FWD
OFF→ON
ON
ON
ON
OFF
ON→
OFF
Note: For the 2-wire running mode, when
FWD/REV terminal is valid, the VFD stop
because of the stopping command from other
sources, even the control terminal FWD/REV
keeps valid; the VFD won't work when the
stopping command is canceled. Only when
FWD/REV is re-launched, the VFD can start
again. For example, the valid STOP/RST stop
when PLC signal cycles stop, fixed-length stop
and terminal control (see P07.04).
The function code defines the corresponding
delay time of electrical level of the programmable
terminals from switching on to switching off.
Si electrical level
invalid
Si valid
Switcn-on
delay
Setting range: 0.000 – 50.000s
FWD
SIn
REV
COM
REV
Direction
ON
OFF
OFF→ON
Decelerate
valid
Switcn-off
delay
61
Function parameters
Default
value
Forward
Reverse
Forward
Reverse
to stop
0.000s
0.000s
invalid
0.000s
0.000s
Modify
○
○
○
○
