Goodrive20-EU series VFD
Function
Name
code
B frequency
command
P00.08
reference
selection
Combination of
P00.09 the setting
source
Keypad set
P00.10
frequency
Acceleration
P00.11
time 1
Deceleration
P00.12
time 1
Detailed instruction of parameters
0: Maximum output frequency, 100% of B
frequency setting corresponds to the maximum
output frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max. (A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min. (A, B): The lower one between A
frequency command and B frequency is the set
frequency.
Note: The combination manner can be shifted by
P05 (terminal function)
When A and B frequency commands are
selected as "keypad setting", this parameter will
be the initial value of VFD reference frequency
Setting range: 0.00 Hz –P00.03 (the max.
frequency)
Acceleration time means the time needed for the
VFD to speed up from 0Hz to the maximum
output frequency (P00.03).
Deceleration time means the time needed if the
VFD speeds down from the maximum output
frequency (P00.03) to 0Hz.
Goodrive20-EU series VFDs have four groups of
acceleration/deceleration time which can be
selected by P05. The default
36
Function parameters
Default
Modify
value
○
0
○
0
○
50.00Hz
Depend
○
on
model
Depend
○
on
model
