Goodrive20-EU series VFD
Function
Name
code
PID command
acceleration/
P09.15
deceleration
time
PID output filter
P09.16
time
Low frequency
P09.17
proportional
gain (Kp)
Low frequency
P09.18
integral time
(Ti)
Low frequency
P09.19
differential time
(Td)
Low point
frequency of
P09.20
PID parameter
switching
High point
frequency of
P09.21
PID parameter
switching
P10 Group Simple PLC and multi-step speed control
Simple PLC
P10.00
mode
Detailed instruction of parameters
1: main reference A frequency source buffering
acceleration/deceleration is valid and the
acceleration/deceleration is determined by
P08.04.
0.0 – 1000.0s
0.000 – 10.000s
0.00 – 100.00
0.00 – 10.00s
0.00 – 10.00s
0.00Hz – P09.21
When the ramp frequency is no greater than
P09.20, current PID parameters are P09.17 –
P09.19. When the ramp frequency is no less
than P09.21, current PID parameters are P09.04
– P09.06. The medium frequency range is the
linear interpolation values between the two PID
parameter groups.
P09.20 – P00.03
0: Stop after running once. The VFD has to be
commanded again after finishing a cycle.
1: Run at the final value after running once. After
finish a signal, the VFD will keep the running
frequency and direction of the last run.
87
Function parameters
Default
Modify
value
○
0.0s
○
0.000s
○
1.00
○
0.10s
○
0.00s
○
5.00Hz
○
10.00Hz
○
0
