C.6.5 C2 filter
Model
GD20-0R4G-S2-EU
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
GD20-0R7G-2-EU
GD20-1R5G-2-EU
GD20-2R2G-2-EU
GD20-004G-2-EU
GD20-5R5G-2-EU
GD20-7R5G-2-EU
GD20-0R7G-4-EU
GD20-1R5G-4-EU
GD20-2R2G-4-EU
GD20-004G-4-EU
GD20-5R5G-4-EU
GD20-7R5G-4-EU
GD20-011G-4-EU
GD20-015G-4-EU
GD20-018G-4-EU
GD20-022G-4-EU
GD20-030G-4-EU
GD20-037G-4-EU
GD20-045G-4-EU
GD20-055G-4-EU
GD20-075G-4-EU
GD20-090G-4-EU
GD20-110G-4-EU
Note:
1. The input EMI meet the requirement of C2 after adding input filters.
2. Above options are external, the customer should indicate when purchasing.
C.7 Brake components
C.7.1 Select the brake components
It is appropriate to use brake resistor or brake unit when the motor brakes sharply or the motor
Input filter
FLT-PS2010H-B
FLT-PS2025L-B
FLT-P04006L-B
FLT-P04016L-B
FLT-P04032L-B
FLT-P04045L-B
FLT-P04006L-B
FLT-P04016L-B
FLT-P04032L-B
FLT-P04045L-B
FLT-P04065L-B
FLT-P04100L-B
FLT-P04150L-B
FLT-P04240L-B
159
Peripheral options and parts
Output filter
FLT-L04006L-B
FLT-L04016L-B
FLT-L04006L-B
FLT-L04016L-B
FLT-L04032L-B
FLT-L04045L-B
FLT-L04006L-B
FLT-L04016L-B
FLT-L04032L-B
FLT-L04045L-B
FLT-L04065L-B
FLT-L04100L-B
FLT-L04150L-B
FLT-L04240L-B
