Goodrive20-EU series VFD
Function
Name
code
Current
regulation
P08.51
coefficient on
input side
P09 Group PID control
PID reference
P09.00
source
Keypad PID
P09.01
preset
PID feedback
P09.02
source
Detailed instruction of parameters
This function code is used to adjust the displayed
current of the AC input side.
Setting range: 0.00 – 1.00
When the frequency command selection
(P00.06, P00. 07) is 7 or the voltage setting
channel selection (P04.27) is 6, the running
mode of the VFD is procedure PID controlled.
The parameter determines the target given
channel during the PID procures.
0: Keypad (P09.01)
1: AI1
2: AI2
3: AI3
4: High speed pulse HDI
5: Multi-step speed
6: MODBUS communication
7 – 9: Reserved
The setting target of process PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the
relative value (0 – 100.0%).
Note: Given by multi-step speed is realized by
setting P10 group parameters.
When P09.00=0, set the parameter whose basic
value is the feedback value of the system.
Setting range: -100.0% – 100.0%
Select the PID channel by the parameter.
0: AI1
1: AI2
2: AI3
3: High speed HDI
4: MODBUS communication
5: Max (|AI2|, |AI3|)
6–7: Reserved
83
Function parameters
Default
Modify
value
○
0.56
○
0
○
0.0%
○
0
