INVT Goodrive20-EU VFD Series Operation Manual page 67

Goodrive20-EU series VFD
Function
Name
code
AI2
Upper limit of
P05.39
AI2
Corresponding
setting of
P05.40
the upper limit
of AI2
AI2 input filter
P05.41
time
Lower limit of
P05.42
AI3
Corresponding
setting of the
P05.43
lower limit of
AI3
Middle value of
P05.44
AI3
Corresponding
P05.45 middle setting
of AI3
Upper limit of
P05.46
AI3
Corresponding
setting of
P05.47
the upper limit
of AI3
AI3 input filter
P05.48
time
Lower limit
P05.50 frequency of
HDI
Detailed instruction of parameters
-10V
Al3
Input filter time: this parameter is used to adjust
the sensitivity of the analog input. Increasing the
value properly can enhance the anti-interference
of the analog, but weaken the sensitivity of the
analog input
Note: AI1 supports 0 – 10V input and AI2
supports 0 – 10V or 0 – 20mA input, when AI2
selects 0 – 20mA input, the corresponding
voltage of 20mA is 10V. AI3 can support the
output of -10V – +10V.
Setting range of P05.32: 0.00V – P05.34
Setting range of P05.33: -100.0% – 100.0%
Setting range of P05.34: P05.32 – 10.00V
Setting range of P05.35: -100.0% – 100.0%
Setting range of P05.36: 0.000s – 10.000s
Setting range of P05.37: 0.00V – P05.39
Setting range of P05.38: -100.0% – 100.0%
Setting range of P05.39: P05.37 – 10.00V
Setting range of P05.40: -100.0% – 100.0%
Setting range of P05.41: 0.000s – 10.000s
Setting range of P05.42: -10.00V – P05.44
Setting range of P05.43: -100.0% – 100.0%
Setting range of P05.44: P05.42 – P05.46
Setting range of P05.45: -100.0% – 100.0%
Setting range of P05.46: P05.44 – 10.00V
Setting range of P05.48: 0.000s – 10.000s
0.000kHz – P05.52
Corresponding
setting
100%
AI
10V
20mA
AI1/AI2
-100%
63
Function parameters
Default
Modify
value
○
10.00V
○
100.0%
○
0.100s
-10.00
○
V
-100.0
○
%
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.100s
0.000
○
kHz
