INVT Goodrive20-EU VFD Series Operation Manual page 69

Goodrive20-EU series VFD
Function
Name
code
Polarity
selection of
P06.05
output
terminals
Y1 open delay
P06.06
time
Y1C off delay
P06.07
time
RO1 switching
P06.10
on delay time
RO1 switching
P06.11
off delay time
RO2 switching
P06.12
on delay time
RO2 switching
P06.13
off delay time
AO1 output
P06.14
selection
AO2 output
P06.15
selection
Detailed instruction of parameters
21: Reserved
22: Running time arrival
23: MODBUS communication virtual terminals
output
24 – 25: Reserved
26: Establishment of DC bus voltage
27: STO action
28 – 30: Reserved
The function code is used to set the pole of the
output terminal.
When the current bit is set to 0, input terminal is
positive.
When the current bit is set to 1, input terminal is
negative.
BIT3 BIT2
RO2 RO1
Setting range: 0 – F
Setting range: 0.000 – 50.000s
Setting range: 0.000 – 50.000s
The function code defines the corresponding
delay time of the electrical level change during
the programmable terminal switching on and off.
RO electric level
Invalid
RO valid
Switch on
delay
Setting range: 0.000 – 50.000s
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running speed (relative to twice the motor
synchronous rotational speed)
4: Output current (relative to twice the rated VFD
current)
BIT1
Reserved
Valid
Switch off
delay
65
Function parameters
Default
value
0
BIT0
Y1
0.000s
0.000s
0.000s
0.000s
0.000s
invalid
0.000s
0
0
Modify
○
○
○
○
○
○
○
○
○
