Goodrive20-EU series VFD
Function
Name
code
Communication
P14.03
response delay
Communication
P14.04 overtime fault
time
Transmission
P14.05 error
processing
Communication
P14.06 processing
action selection
Detailed instruction of parameters
11: Odd check (O, 7, 2) for ASCII
12: No check (N, 8, 1) for ASCII
13: Even check (E, 8, 1) for ASCII
14: Odd check (O, 8, 1) for ASCII
15: No check (N, 8, 2) for ASCII
16: Even check (E, 8, 2) for ASCII
17: Odd check (O, 8, 2) for ASCII
0 – 200ms
It means the interval time between the drive
receive the data and sent it to the upper monitor.
If the answer delay is shorter than the system
processing time, then the answer delay time is
the system processing time, if the answer delay
is longer than the system processing time, then
after the system deal with the data, waits until
achieving the answer delay time to send the data
to the upper monitor.
0.0 (invalid), 0.1 – 60.0s
When the function code is set as 0.0, the
communication overtime parameter is invalid.
When the function code is set as non-zero, if the
interval time between two communications
exceeds the communication overtime, the
system will report "485 communication faults"
(CE).
0: Alarm and stop freely
1: No alarm and continue running
2: No alarm and stop as per the stop mode (only
under communication control mode)
3: No alarm and stop as per the stop mode
(under all control modes)
0x000 – 0x111
LED ones: Responding to write operations
0: Yes
1: No
LED tens: Communication encryption
0: Disabled
97
Function parameters
Default
Modify
value
○
5
○
0.0s
○
0
○
0x000
