Goodrive20-EU series VFD
Function
Name
code
Current
P17.26
running time
Simple PLC
and present
P17.27 stage of
multi-step
speed
ASR controller
P17.28
output
P17.29 Reserved
P17.30 Reserved
P17.31 Reserved
Magnetic flux
P17.32
linkage
Exciting current
P17.33
reference
Torque current
P17.34
reference
AC input
P17.35
current
P17.36 Output torque
Motor overload
P17.37
counting
P17.38 PID output
Parameter
P17.39
download error
Process PID
P17.40 proportional
gain
Process PID
P17.41
integral time
Process PID
P17.42
differential time
Detailed instruction of parameters
Display the current running time of the VFD.
Range: 0 – 65535min
Display simple PLC and the current stage of the
multi-step speed
Range: 0 – 15
The percentage of the rated torque of the relative
motor, display ASR controller output
Range: -300.0% – 300.0% (rated motor current)
Display the magnetic flux linkage of the motor.
Range: 0.0% – 200.0%
Display the exciting current reference in the
vector control mode.
Range: -3000.0 – 3000.0A
Display the torque current reference in the vector
control mode.
Range: -3000.0 – 3000.0A
Display the input current in AC side.
Range: 0.0 – 5000.0A
Display the output torque. Positive value is in the
electromotion state, and negative value is in the
power generating state.
Range: -3000.0Nm – 3000.0Nm
0 – 100 (OL1 when 100)
Display PID output
-100.00 – 100.00%
0.00 – 99.99
0.00 – 100.00
0.00 – 10.00s
0.00 – 10.00s
100
Function parameters
Default
Modify
value
●
●
●
●
●
●
●
●
●
●
●
●
●
●
0.00
●
●
●
