Goodrive20-EU series VFD
Function instruction
Address of the
communication n
setting value
Address
definition
0003H: forward jogging
0004H: reverse jogging
0005H: stop
0006H: coast to stop (emergency stop)
0007H: fault reset
0008H: jogging stop
Communication setting frequency (0 –
2001H
Fmax(unit: 0.01Hz))
PID reference, range (0 – 1000, 1000
2002H
corresponds to100.0% )
PID feedback, range (0 – 1000, 1000
2003H
corresponds to100.0% )
Torque setting value (-3000 – 3000, 1000
2004H
corresponds to the 100.0% of the rated
current of the motor)
The upper limit frequency setting during
forward rotation (0 – Fmax (unit:
2005H
0.01Hz))
The upper limit frequency setting during
reverse rotation (0 – Fmax (unit:
2006H
0.01Hz))
The upper limit torque of electromotion
torque (0 – 3000, 1000 corresponds to
2007H
the 100.0% of the rated current of the
motor)
The upper limit torque of braking torque
(0 – 3000, 1000 corresponds to the
2008H
100.0% of the rated current of the motor)
Special control command word
Bit0 – 1: =00: motor 1
Bit2: =1 torque control prohibit
2009H
=0: torque control prohibit invalid
Bit3: =1 power consumption clear
=0: no power consumption clear
Bit4: =1 pre-exciting =0:
pre-exciting prohibition
129
Data meaning instruction
=10: motor 3
=11: motor 4
Communication protocol
attribute
=01: motor 2
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
