INVT Goodrive20-EU VFD Series Operation Manual page 77

Goodrive20-EU series VFD
Function
Name
code
P07.33 Reference frequency of present fault
P07.34 Ramps reference frequency of present fault
P07.35 Output voltage of present fault
P07.36 Output current of present fault
P07.37 Bus voltage of present fault
P07.38 Max. temperature of present fault
P07.39 Input terminals state of present fault
P07.40 Output terminals state of present fault
P07.41 Running frequency of the last fault
P07.42 Ramps reference frequency of the last fault
P07.43 Output voltage of the last fault
P07.44 Output current of the last fault
P07.45 Bus voltage of the last fault
P07.46 Max. temperature of the last fault
P07.47 Input terminals state of the last fault
P07.48 Output terminals state of the last fault
P07.49 Reference frequency of the last but one fault
P07.50 Ramp reference frequency of last but one fault
P07.51 Output voltage of the last but one fault
P07.52 Output current of the last but one fault
P07.53 Bus voltage of the last but one fault
P07.54 Max. temperature of the last but one fault
P07.55 Input terminals state of the last but one fault
P07.56 Output terminals state of the last but one fault
P08 Group Enhanced functions
Acceleration
P08.00
time 2
Deceleration
P08.01
time 2
Acceleration
P08.02
time 3
Deceleration
P08.03
time 3
Detailed instruction of parameters
40: Channel 1 and channel 2 become abnormal
simultaneously (STL3)
41: Safety code FLASH CRC check fault (CrCE)
When terminals are used for acceleration/
deceleration time selection (see terminal function
settings in the P05 group), the four groups of
acceleration/deceleration time are selected
based on the states of Acceleration/deceleration
time selection terminal 1 (21) and
Acceleration/deceleration time selection terminal
2 (22).
73
Function parameters
Default
Modify
value
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0.0V
●
0.0° C
●
0
●
0
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0.0V
●
0.0° C
●
0
●
0
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0.0V
●
0.0° C
●
0
●
0
○
○
Depend
on
model
○
