Goodrive20-EU series VFD
Function parameters
Function
Default
Name
Detailed instruction of parameters
Modify
code
value
5: Output current (relative to twice the rated
motor current)
6: Output voltage (relative to 1.5 times the rated
VFD voltage)
7: Output power (relative to twice the rated motor
power)
8: Set torque value (relative to twice the rated
motor torque)
9: Output torque (relative to twice the rated motor
torque)
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: High-speed pulse HDIA input value
14: Value 1 set through Modbus communication
15: Value 2 set through Modbus communication
16: Value 1 set through
PROFIBUS/CANopen/DeviceNet communication
17: Value 2 set through
PROFIBUS/CANopen/DeviceNet communication
18: Value 1 set through Ethernet communication
19: Value 2 set through Ethernet communication
20: High-speed pulse HDIB input value
21: Value 1 set through EtherCAT/PROFINET
communication
22: Torque current (relative to 3 times the rated
motor current)
23: Ramp reference frequency
24: Set frequency (bipolar)
25: Ramp reference frequency (bipolar)
26: Running speed (bipolar)
27: Value 2 set through EtherCAT/PROFINET
communication
28: C_AO1 from PLC (P27.00 must be 1.)
29: C_AO2 from PLC (P27.00 must be 1.)
30: Running speed (relative to twice the motor
synchronous rotational speed)
31–47: Reserved variable
66
