Goodrive20-EU series VFD
Function
Name
code
Rectifier bridge
P07.11
module
temperature
Converter
P07.12
module
temperature
Software
P07.13
version
Local
P07.14
accumulative
running time
High bit of
P07.15
power
consumption
Low bit of
P07.16
power
consumption
P07.17
Reserved
Rated power of
P07.18
the VFD
Rated voltage
P07.19
of the VFD
Rated current
P07.20
of the VFD
Factory bar
P07.21
code 1
Factory bar
P07.22
code 2
Factory bar
P07.23
code 3
Factory bar
P07.24
code 4
Factory bar
P07.25
code 5
P07.26
Factory bar
code 6
Detailed instruction of parameters
-20.0 – 120.0° C
-20.0 – 120.0° C
1.00 – 655.35
0 – 65535h
Display the power used by the VFD.
The power consumption of the VFD
=P07.15×1000+P07.16
Setting range of P07.15: 0 – 65535 kWh (*1000)
Setting range of P07.16: 0.0 – 999.9 kWh
Reserved
0.4 – 3000.0kW
50 – 1200V
0.1 – 6000.0A
0x0000 – 0xFFFF
0x0000 – 0xFFFF
0x0000 – 0xFFFF
0x0000 – 0xFFFF
0x0000 – 0xFFFF
0x0000 – 0xFFFF
71
Function parameters
Default
Modify
value
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
