Goodrive20-EU series VFD
is driven by a high inertia load. The motor will become a generator if its actual rotating speed is
higher than the corresponding speed of the reference frequency. As a result, the inertial
energy of the motor and load return to the VFD to charge the capacitors in the main DC circuit.
When the voltage increases to the limit, damage may occur to the VFD. It is necessary to
apply brake unit/resistor to avoid this accident happens.
Goodrive20-EU series VFDs have internal brake units.
Model
GD20-0R4G-S2-EU
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
GD20-0R7G-2-EU
GD20-1R5G-2-EU
GD20-2R2G-2-EU
GD20-004G-2-EU
GD20-5R5G-2-EU
GD20-7R5G-2-EU
GD20-0R7G-4-EU
GD20-1R5G-4-EU
GD20-2R2G-4-EU
Only qualified electricians are allowed to design, install, commission and
operate on the VFD.
Follow the instructions in "warning" during working. Physical injury or
death or serious property may occur.
Only qualified electricians are allowed to wire. Damage to the VFD or
brake options and part may occur. Read carefully the instructions of
brake resistors or units before connecting them to the VFD.
Do not connect the brake resistor to other terminals except for PB and
(-). Do not connect the brake unit to other terminals except for (+) and
(-).Damage to the VFD or braking circuit or fire may occur.
Connect the brake resistor or brake unit to the VFD according to the
diagram. Incorrect wiring may cause damage to the VFD or other
devices.
Brake
resistor at
Type of
100% of
brake unit
braking
torque (Ω)
361
192
361
192
Internal
brake unit
653
326
222
Consumed power of the brake
10%
braking
0.06
0.11
96
0.23
65
0.33
0.06
0.11
96
0.23
65
0.33
36
0.6
26
0.75
19
1.13
0.11
0.23
0.33
160
Peripheral options and parts
resistor (kW)
50%
80%
braking
braking
0.30
0.48
0.56
0.90
1.10
1.80
1.70
2.64
0.3
0.48
0.56
1.1
1.7
2.64
3
4.13
5.63
0.56
0.90
1.13
1.80
1.65
2.64
Min.
brake
resistor
(Ω)
42
42
30
21
131
0.9
93
1.8
44
44
4.8
33
6.6
25
9
13
240
170
130
