Goodrive20-EU series VFD
Function
Name
code
User-defined
address for
P14.07
running
commands
User-defined
address for
P14.08
frequency
setting
P17 Group Monitoring function
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02
reference
frequency
P17.03 Output voltage
P17.04 Output current
P17.05
Motor speed
P17.06 Torque current
Magnetized
P17.07
current
P17.08
Motor power
P17.09 Output torque
Detailed instruction of parameters
1: Enabled
LED hundreds: User-defined communication
command address
0: Disabled
1: Enabled
0x0000–0xffff
0x0000–0xffff
Display current set frequency of the VFD
Range: 0.00Hz – P00.03
Display current output frequency of the VFD
Range: 0.00Hz – P00.03
Display current ramp reference frequency of the
VFD
Range: 0.00Hz – P00.03
Display current output voltage of the VFD
Range: 0 – 1200V
Display current output current of the VFD
Range: 0.0 – 5000.0A
Display the rotation speed of the motor.
Range: 0 – 65535RPM
Display current torque current of the VFD
Range: 0.0 – 5000.0A
Display current magnetized current of the VFD
Range: 0.0 – 5000.0A
Display current power of the motor.
Setting range: -300.0% – 300.0%
(the rated current of the motor)
Display the current output torque of the VFD.
Range: -250.0 – 250.0%
98
Function parameters
Default
Modify
value
○
0x1000
○
0x2000
●
●
●
●
●
●
●
●
●
●
