Goodrive20-EU series VFD
Function
Name
code
Overmodulation
P08.41
selection
Keypad digital
P08.42
control setting
Detailed instruction of parameters
two-phase modulation
1: PWM mode 2, three-phase modulation
LED tens: low-speed carrier frequency limit
mode
0: Low-speed carrier frequency limit mode 1, the
carrier frequency will limit to 1k or 2k if it exceeds
2k at low speed
1: Low-speed carrier frequency limit mode 2, the
carrier frequency will limit to 4k if it exceeds 4k at
low speed
2: No limit
LED ones
0: Disabled
1: Enabled
LED tens
0: Light overmodulation; restricted in zone 1
1: Heavy overmodulation; restricted in zone 2
For VFDs of 1PH 220V/3PH 380V (≤2.2kW) and
3PH 220V (≤0.75kW), the default value is 00;
for those of 3PH 380V (≥4kW) and 3PH 220V
(≥1.5kW), the default value is 01.
0x0000 – 0x1223
LED ones: frequency enable selection
0: Both ∧/∨ keys and analog potentiometer
adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only analog potentiometer adjustments is
valid
3: Neither ∧/∨ keys nor digital potentiometer
adjustments are valid
LED tens: frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting modes
2: Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: action selection during stopping
0: Setting is valid
1: Valid during running, cleared after stopping
80
Function parameters
Default
Modify
value
0x00
◎
0x01
○
0x0000
