INVT Goodrive20-EU VFD Series Operation Manual page 78

Goodrive20-EU series VFD
Function
Name
code
Acceleration
P08.04
time 4
Deceleration
P08.05
time 4
Jog running
P08.06
frequency
Jogging
running
P08.07
acceleration
time
Jogging
running
P08.08
deceleration
time
Jumping
P08.09
frequency 1
Jumping
P08.10 frequency
range 1
Jumping
P08.11
frequency 2
Jumping
P08.12 frequency
range 2
Detailed instruction of parameters
Terminal Terminal
1 (21) 2 (22)
OFF OFF
deceleration time 1
ON OFF
deceleration time 2
OFF ON
deceleration time 3
ON ON
deceleration time 4
Refer to P00.11 and P00.12 for detailed
definition.
The first group of acceleration/deceleration time
is the factory default one.
Setting range: 0.0 – 3600.0s
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz – P00.03 (the max.
frequency)
The jogging acceleration time means the time
needed if the VFD runs from 0Hz to the max.
frequency.
The jogging deceleration time means the time
needed if the VFD goes from the max. frequency
(P00.03) to 0Hz.
Setting range: 0.0 – 3600.0s
When the set frequency is in the range of
jumping frequency, the VFD will run at the edge
of the jumping frequency.
The VFD can avoid the mechanical resonance
point by setting the jumping frequency. The VFD
can set three jumping frequency. But this
function will be invalid if all jumping points are 0.
Acceleration or Corresponding
deceleration time
Acceleration/
Acceleration/
Acceleration/
Acceleration/
74
Function parameters
Default
value
parameters
P00.11/
P00.12
P08.00/
P08.01
P08.02/
P08.03
P08.04/
P08.05
5.00Hz
Depend
on
model
0.00Hz
0.00Hz
0.00Hz
0.00Hz
Modify
○
○
○
○
○
○
○
○
○
