Goodrive20-EU series VFD
Function instruction
SW 1 of the VFD
SW 1 of the VFD
VFD fault code
Identifying code of the
VFD
Operation frequency
Address
definition
Bit5: =1 DC braking =0: DC
braking prohibition
Virtual input terminal command, range:
200AH
0x000 – 0x1FF
Virtual output terminal command, range:
200BH
0x00 – 0x0F
Voltage setting value (special for V/F
separation)
200CH
(0 – 1000, 1000 corresponds to the
100.0% of the rated voltage of the motor)
AO output setting 1
(-1000 – 1000, 1000 corresponds to
200DH
100.0%)
AO output setting 2
(-1000 – 1000, 1000 corresponds to
200EH
100.0%)
0001H: forward running
0002H: forward running
0003H: stop
2100H
0004H: fault
0005H: POFF state
0006H: pre-exciting state
Bit0: =0: bus voltage is not established
=1: bus voltage is established
Bi1 – 2: =00: motor 1
Bit3: =0: asynchronous motor =1:
2101H
Bit4: =0: pre-alarm without overload
=1:overload pre-alarm
Bit5 – Bit6 :=00: keypad control
=01: terminal control
=10: communication control
2102H
See the fault type instruction
2103H
GD20-----0x0106
Range: 0.00Hz – P00.03
3000H
130
Data meaning instruction
=01: motor 2
=10: motor 3
=11: motor 4
synchronous motor
Communication protocol
R/W
attribute
R/W
R/W
R/W
R/W
R/W
R
R
R
R
R
