INVT Goodrive20-EU VFD Series Operation Manual page 24

Goodrive20-EU series VFD
RO1A RO1B RO1C
RO2A RO2B RO2C
Terminal
Type
Communication
Digital
input/output
STO function
input
24V power
supply
S1 S2 S3
+24V PW COM
Figure 3-11 Connection terminal diagram for VFDs ≥ 4kW
Function
name description
485+
485 communication 485 communication interface
485-
S1
S2
Digital input
S3
S4
High frequency
HDI
input channel
PW Digital power supply
Y1 Digital output
24V-H1 STO input 1
24V-H2 STO input 2
+24V
24V power supply
COM
S4 HDI Y1 AI2
COM GND AO1 AO2
1. Internal impedance: 3.3kΩ
2. 12 – 30V voltage input is available
3. The terminal is the dual-direction input
terminal
4. Max. input frequency: 1kHz
Except for S1 – S4, this terminal can be
used as high frequency input channel.
Max. input frequency: 50kHz
Duty cycle: 30% – 70%
The working power of digital input is
provided by an external power supply.
Power range: 12 V–30 V
1. Contact capacity: 50mA/30V;
2. Output frequency range: 0 – 1kHz;
3. Default is STO state output indicator.
1. Safe torque stop (STO) redundant input,
externally connected to NC contact, STO
acts when the contact is open, and the
drive stops output;
2. The safe input signal cable should be
shield cable within 25m.
3. When employing STO function, please
disassemble the short circuit plate on the
terminals shown in fig 3.10 and fig 3.11.
External 24V±10% power supply and the
maximum output current is 200mA。
Generally used as the operation power
supply of digital input and output or external
sensor power supply
20
AI3 +10V
485+ 485- +24V
Technical specifications
Installation guide
H1 +24V H2
