Goodrive20-EU series VFD
4 Keypad operation procedure
4.1 Keypad introduction
The keypad is used to control Goodrive20-EU series VFDs, read the state data and adjust
parameters.
Note:
1. The film keypad is standard for the VFDs of 1PH 230V/3PH 400V (≤2.2kW) and the VFDs
of 3PH (≤0.75kW). The external keypad is standard for the VFDs of 3PH 400V (≥4kW) and
3PH 230V (≥1.5kW).
2. The external keypads are optional (including the external keypads with and without the
function of parameter copying).
RUN/TUNE
FWD/REV
LOCAL/REMOT
TRIP
PRG
ESC
QUICK
JOG
RUN
Figure 4-1 Film keypad
RUN/TUNE
FWD/REV
LOCAL/REMOT
TRIP
3
PRG
ESC
QUICK
JOG
STOP
4
RUN
RST
Figure 4-2 External keypad
26
Keypad operation procedure
1
HZ
2
RPM
A
%
V
DATA
SHIFT
STOP
RST
1
HZ
RPM
A
%
V
2
5
DATA
SHIFT
