IN1508 – Setup Guide
N For full installation, configuration, and operation details, refer to the
IN1508 User's Manual, available at www.extron.com.
This guide provides quick start instructions for an experienced installer to set up and
operate the Extron IN1508 Scaling Presentation Switcher.
Installation and cabling
100-240V 50-60Hz
1 3
I
VID YC
N
P
VID YC
U
T B-Y
Y
2 4 5
50/60Hz
1 2 3 4
Connections
a
AC power connector
b
Inputs 1 and 2 composite video BNC connectors
c
Inputs 3 and 4 S-video mini-DIN connectors
d
Input 5 component video BNC connectors
e
Inputs 6 and 7 RGB video 15-pin HD connectors
f
Input 8 DVI video connector (DVI-D only)
Step 1 — Mounting
Turn off or disconnect all equipment power sources. For tabletop use, affix the rubber feet. For
optional rack mounting, secure the supplied brackets (see image at right) and mount in a rack.
Step 2 — Video inputs and output
Inputs 1 and 2 — Connect composite video
a.
sources to these female BNC connectors.
b. Inputs 3 and 4 — Connect S-video sources
to these 4-pin mini DIN connectors.
c. Input 5 — Connect a component video
(YUVi, YUVp, HDTV) source to these
female BNC connectors.
Inputs 6 and 7 — Connect RGB video sources to
d.
these 15-pin HD connectors.
Input 8 — Connect a single link of DVI-D video
e.
to this DVI-I connector.
Output — Connect an RGB or component video
f.
display to this 15-pin HD output female connector.
Step 3 — Audio inputs and outputs
a. Audio Inputs 1 through 5 RCA connectors —
Connect stereo or mono audio sources.
b. Audio Inputs 6 through 8 3.5 mm mini jacks — Connect computer
audio sources.
c. Output A RCA audio connectors — Connect a stereo or mono audio
device (receiver, amplifier, or the like).
— OR —
Output B audio captive screw connector — Connect a stereo or mono
audio device (receiver, amplifier, or the like); wire the connector as shown
at right.
6
OUTPUT
LISTED
1T23
C U S
I.T.E.
RGB
RGB Y, B-Y, R-Y
R-Y RGB DVI
7 8
5 6 7
AUDIO INPUT OUTPUT
1 2 3 4 5 6 A
L
L
B
7 8 L R
R
R
8 9 10 11
g
Output 15-pin HD connector
h
Audio Inputs 1 through 5 RCA connectors
i
Audio Inputs 6 through 8 3.5 mm mini stereo jacks
j
Audio Output A RCA connectors
k
Audio Output B captive screw connector
l
RS-232 9-pin D connector
1 3
I
VID YC YC
N
P
VID YC
U
T
2 4
R-Y
Y B-Y
5
6
RGB
RGB DVI
7 8
OUTPUT
1
RGB
L
Y, B-Y, R-Y
R
RS-232
12
Y C
3
C -Y
1 V ID
5
B -Y
I
z
-6 0H
50
N V ID Y
0- 24 0V
10
P 4
U
2
T
AUDIO INPUT
2 3 4 5 6
L
7 8
R
Tip
Ring
Tip
Ring
Balanced Stereo Output
For unbalanced audio output, connect
CAUTION
the sleeve(s) to the ground contact.
DO NOT connect the sleeve(s) to the
negative (-) contacts).
U T
T P
O U
A
B
R
L
L
6
5
U T R
8
IN P
4
7
D IO
A U
3
2
U T
T P L
O U
R G B -Y
D , C R
TE B -Y
LIS 23
1T .E. Y,
U S I.T
C
6
D V I
R G B
7
B
R G
OUTPUT
A
B
L R
Tip
NO GROUND HERE.
Sleeve(s)
Tip
NO GROUND HERE.
Unbalanced Stereo Output
