ROBOTIQ 2-Finger Adaptive Robot Gripper - 200 Instruction Manual page 25

Robotiq 2-Finger Adaptive Robot Gripper - 200
Figure 3.5.3 : Gripper Signal Cable for the Robotiq 2-Finger Adaptive Robot Gripper
Info
Gripper signal cable is supplied by Robotiq, see
Warning
Use proper cabling management. Be sure to have enough forgiveness in the cabling to allow
movement of the Gripper along all axes without pulling out the connectors. Always protect the
controller-side of the cable with a strain relief cable clamp.
Robotiq inc. © 2008-2013
Spare Parts, Kits and Accessories
Instruction Manual
– 200.
section.
25
