Step 6: Move the robot to the release location
Step 7: Open the Gripper at full speed and full force
Request is:
34 AB 00 00 00 0D 02 10 00 00 00 03 06 09 00 00 00 FF FF
where
Robotiq inc. © 2008-2013
Bits
34AB
0000
000D
02
10
0000
0003
06
0900
0000
FFFF
Description
Unique transaction identifier (chosen randomly)
Protocol Identifier (Modbus)
Length
SlaveID
Function Code 16 (Preset Multiple Registers)
Address of the first register
Number of registers to write to
Number of data bytes to follow (3 registers x 2
bytes/register = 6 bytes)
Value to write to register 0x0000 (ACTION REQUEST
= 0x09 and GRIPPER OPTIONS = 0x00): rACT = 1 for
"Activate Gripper" rGTO = 1 for "Go to Requested ,
Position"
Value to write to register 0x0001 (GRIPPER OPTIONS
2 = 0x00 and POSITION REQUEST = 0x00): rPR =
0/255 for full opening of the Gripper (partial
opening would also be possible)
Value to write to register 0x0002 (SPEED = 0xFF and
FORCE = 0xFF): full speed and full force
