General Presentation - ROBOTIQ 2-Finger Adaptive Robot Gripper - 200 Instruction Manual

Robotiq 2-Finger Adaptive Robot Gripper - 200

1. General Presentation

The terms "Gripper", "Adaptive Gripper", "Robotiq Gripper", "Robotiq Adaptive Gripper", "B-Model", "2-Finger
Gripper" and "2-Finger
Gripper – 200 .
Note
The following manual uses the metric system, unless specified, all dimensions are in
millimeters
Note
The following section presents the key features of the Gripper and must not be considered as
appropriate to Gripper operation, each feature is detailed in appropriate sections of the manual.
Safety guidelines must be read and understood before any operation is attempted with the
Gripper.
The 2-Finger Adaptive Robot Gripper
featuring high grip force, rugged design and sealed casing. Its design makes it a unique robotic end-of-arm tool to
quickly pick, place and handle a large range of parts of varying sizes and shapes.
The Gripper has two articulated fingers that each have two joints (two phalanxes per finger), as shown in Figure 1.1.
The Gripper can engage up to six contact points with an object (two on each of the phalanges and on the palm). The
fingers are underactuated, meaning they have fewer motors than the total number of joints. This configuration allows
the fingers to automatically adapt to the shape of the object they grip and it also simplifies the control of the Gripper.
Robotiq inc. © 2008-2013
– 200" used in the following manual all refer to the
.
– 200 is an electric robot peripheral that is designed for industrial applications,
