Robotiq 2-Finger Adaptive Robot Gripper - 200
where
Step 9: Loop back to step 3 if other objects have to be gripped.
Robotiq inc. © 2008-2013
09 03 06 F9 00 00 00 0D 00 56 4C
Bits
09
03
06
F900
0000
0D00
564C
Description
SlaveID
Function Code 03 (Read Holding Registers)
Number of data bytes to follow (3 registers x 2
bytes/register = 6 bytes)
Content of register 07D0 (GRIPPER STATUS = 0xF9,
RESERVED = 0x00): gACT = 1 for "Gripper Activation",
gGTO = 1 for "Go to Position Request" and gOBJ = 3
for "Fingers are at requested position"
Content of register 07D1 (FAULT STATUS = 0x00,
POSITION REQUEST ECHO = 0x00): the position
request echo tells that the command was well received
and that the GRIPPER STATUS is valid.
Content of register 07D2 (POSITION = 0x0D, FINGER
CURRENT = 0x00): the position is 13/255 (the fingers
have reached their software limit)
Cyclic Redundancy Check (CRC)
Instruction Manual
65
