Robotiq 2-Finger Adaptive Robot Gripper - 200
Figure 6.4.3.2 : Working envelope of the Gripper (centered on the Palm Pad).
Modifying the Gripper fingers by any means (drilling holes, adding fixtures, etc.) without Robotiq
Engineering Service approval does not respect safety measures and warranty conditions. Never
modify the Gripper without consent from Robotiq.
Robotiq inc. © 2008-2013
Instruction Manual
95
