Robotiq 2-Finger Adaptive Robot Gripper - 200
Finger Pad
Proximal Pad
Palm Pad
B-009
1
Pitch Circle Diameter
Robotiq inc. © 2008-2013
includes :
one (1) B-012 Finger Pad.
four (4) Y-826 M6 x 12mm Socket
Head Cap Screws.
four (4) Y-931 DIN 7980 M6
locking rings.
includes :
one (1) B-011 Proximal Pad.
four (4) Y-826 M6 x 12mm Socket
Head Cap Screws.
includes :
one (1) B-010 Palm Pad.
four (4) Y-828 M6 x 25mm Socket
Head Cap Screws.
two (2) Y-995 m6 x 24 mm ISO
2338 dowel pins.
One (1) 12.7mm (0.5 in) Palm Pad
Spacer model B-009.
Instruction Manual
AGB-PAD-B012
AGB-PAD-B011
AGB-PAD-B010
AGB-PAD-B009
