Robotiq 2-Finger Adaptive Robot Gripper - 200
3.4 Power supply specifications
The Gripper needs to be supplied with a DC voltage source. This power supply is not included with the Gripper. The
following table shows the specifications regarding the power supply required to operate the Gripper properly.
Specification
Output voltage
Output current
Ripple
Output regulation
Overvoltage protection
Robotiq recommends the use of the following power supply : TDK-Lambda DPP480 Series, 480W Single Output
DIN Rail Mount Power Supplies DDP480-24-1
Robotiq inc. © 2008-2013
1. The Gripper has built-in over-voltage protection.
,
Instruction Manual
Value
24 V DC
20A
2-3 % peak-peak
2% maximum
1
Not required
22
