XVME-678/688 Manual
July 1994
3.3.6.3 Test Control Options
The fields at the top of the screen are options that control how the tests are performed. These options
must be set before a test or tests are initiated.
Continuous Test
Set to yes or no. When set to yes, the test is performed continuously until
<
Esc>
is pressed to stop it. After pressing
<
Esc>, press the space bar to continue or
press
<
Esc> to abort the test(s). Continuous test works with a single test (selected
by
<
FlO
»
or several tests (selected by
<
F9
».
Stop on Error
Echo to LPTI
Set to yes or no. When set to yes, the diagnostic system stops after detecting an
error. After the system reports the error, press the space bar to continue or
<
Esc> to end testing.
Set to yes or no. If set to yes, the test result data is written to a printer attached to
LPTl. This feature is useful if Continuous Test is set to Yes, Stop on Error is set
to No, and run the test(s) unattended.
NOTE
Some of the submenu tests require response to prompts. These are
identified as interactive. If performing continuous unattended tests, do not
select any interactive tests.
3.3.6.4 System. Board
This selection tests the processor, DMA registers, CMOS RAM, real time clock, timers, and interrupt
controller. After the tests are completed, press
<
Esc> to return to the Diagnostics Menu or the space
bar to run the tests again.
3.3.6.5 Keyboard
After Keyboard test is selected, a menu appears that allows the keyboard and controller tests to be enabled
or disabled.
<
F7 > selects all tests, while
<
F8 > sets all tests to No.
After pressing
<
FlO > to accept the selections, a keyboard map appears that is appropriate to the type
of keyboard specified under Diagnostics Keyboard. Press
<
Ctrl >
<
Y > if all keys are working correctly
or
<
Ctrl >
<
N > if there are keys that do not work.
3-19
