Chapter
3 -
BIOS Setup Program
3.3.3.5 SSD Address (QQQOOOOOh)
This indicates the starting address of the SSD in hexadecimal, on 1 Mbyte boundaries. The SSD Address
is set to zero if the SSD Location is XVME-956/101.
3.3.3.6 SSD Device Type (RAM/ROM/FLASH/EEPROM)
This specifies the device type used by the SSD. The EEPROM option is not implemented at this time.
3.3.3.7
XVME-956/101 Device Size (1/2/4 MBits)
This option is only necessary if SSD is in the XVME-956/101. It specifies the size of the devices used
for the SSD. This is necessary only if the SSD Location Field has been set to XVME-956/101. It specifies
whether the devices installed in the XVME-956/101 are 1 Mbit, 2 Mbit, or 4 Mbit devices.
3.3.3.8 On-board Extended BIOS
An extended BIOS may be on-board or off-board. The XVME-678/688 contains an onboard extended
BIOS ROM. An offboard extended BIOS may be located on a module installed in the PC/I04 site. During
power-up, the XVME-678/688 BIOS scans memory to locate any extended BIOS. The onboard extended
BIOS setup options indicate where extended BIOS code is located. All extended BIOS areas are assumed
to be offboard by default. Onboard extended BIOS must be enabled to function properly.
The DOOOO-DFFFF extended BIOS memory ranges are automatically disabled when Solid State Disk
memory is set to XVME-956/101. The EOOO-EFFF memory ranges are automatically disabled when Solid
State Disk memory is set to VMEbus Standard.
3-12
