Numerical
1 Mbyte memory map 4-2
2 Mbyte memory map 4-3
4 Mbyte memory map 4-4
10 Mbyte memory map 4-5
16 Mbyte memory map 4-6
256Kx8 EPROM 2-20, 4-8
80386SX central processing unit 1-4
80387SX math co-processor 2-17
A
Address consistency 4-27
AT-bus speed 3-7
Auto Park Disk 3-13
Auxiliary connector (P7) 2-12
Auxiliary interrupt 4.:18
Auxiliary maskable interrupt structure 4-23
Auxiliary maskable interrupts 4-22
Auxiliary NMI configuration 3-9
Auxiliary non-maskable interrupt (ANMI) functions
5-12
Auxiliary non-maskable interrupt structure 4-25
Auxiliary non-maskable interrupts 4-25
B
Bad track table 3-24
Bank and SIMM Size 2-22
Battery and test jumpers (12, J4) 2-5
BERR 4-12
BERR, SYSFAIL, and ABORT Switch Mapped on
IRQlO 4-24
BIOS
Adding extended 2-20
Shadow 3-6
Xycom extensions 3-1
BIOS Main Menu 3-2
BIOS Setup Menus 3-1
Diagnostics Menu 3-16
Extended BIOS Features Menu 3-13
Function keys 3-1
General instructions 3-2
Setup Menu 3-3
Solid State Disk Setup Menu 3-11
System Information Menu 3-16
VMEbus Master Setup Menu 3-8
B
(continued)
Bus request level 4-13
Byte-ordering schemes 4-26
Intel 4-26
Motorola 4-26
Byte-swapping 3-8, 4-13, 4-26
Address consistency 4-27
Byte-ordering schemes 4-26
Numeric consistency 4-28
C
CMOS 3-1
RAM 3-3, 4-31
RAM address map 4-32
COM A 3-7
COM B 3-7
COMI serial port connector (P9) 2-13
COM2 serial port connector (P8) 2-12
Connectors 2-6
Auxiliary (P7) 2-12
COM1 serial port (P9) 2-13
COM2 serial port (P8) 2-12
Floppy drive (P4) 2-10
IDE hard drive (P5) 2-11
Keyboard (P6) 2-12
Parallel port (JK1) 2-14
PATl 2-16
PXTl 2-15
Speaker (17) 2-14
VGA (P10) 2-13
VMEbus PI 2-8
VMEbus P2 2-9
Control Register 1 4-17
Control Register 2 4-19
Control Register 3 4-20
Control Register 4 4-20
Control Register 5 4-21
Control Register 6 4-21
