3.6 Rated value

3.6.1 AC 3PH 380V(-15%)–440V(+10%) rated value
Product model
GD350-1R5G-4
GD350-2R2G-4
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110G-4
GD350-132G-4
GD350-160G-4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-350G-4
GD350-400G-4
GD350-500G-4
Note:
1. The input current of 1.5–500kW inverter is measured in cases where the input voltage is 380V
without additional reactors;
2. The rated output current is the output current when the output voltage is 380V;
3. Within allowable input voltage range, the output current/power cannot exceed rated output
current/power.
Output power Input current
(kW)
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
-13-
Output
(A) current (A)
5.0 3.7
5.8 5
13.5 9.5
19.5 14
25 18.5
32 25
40 32
47 38
51 45
70 60
80 75
98 92
128 115
139 150
168 180
201 215
265 260
310 305
345 340
385 380
430 425
460 480
500 530
580 600
625 650
715 720
890 860
Chapter 3
Carrier
frequency (kHz)
1–15(8)
1–15(8)
1–15(8)
1–15(8)
1–15(8)
1–15(8)
1–15(4)
1–15(4)
1–15(4)
1–15(4)
1–15(4)
1–15(4)
1–15(4)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
1–15(2)
