INVT Goodrive350 Series Operation Manual page 190

Goodrive350 series high-performance multi-function inverter
Function
Name
code
Control
P13.08
parameter 1
Control
P13.09
parameter 2
Reserved
P13.10
variables
Maladjustment
P13.11
detection time
High-frequency
compensation
P13.12 coefficient of
synchronous
motor
P13.13– Reserved
P13.19 variables
P14 group Serial communication function
Local
P14.00 communication
address
Communication
P14.01
baud rate setup
Detailed parameter description
0–0xFFFF
0–655.35
0–359.9
This parameter is used to adjust the responsiveness
of anti-maladjustment function. If the load inertia is
large, increase the value of this parameter properly,
however, the responsiveness may slow down
accordingly.
Setting range: 0.0–10.0s
This parameter is valid when the motor speed
exceeds the rated speed. If motor oscillation
occurred, adjust this parameter properly.
Setting range: 0.0–100.0%
0–65535
Setting range: 1–247
When the master is writing frames, and the slave
communication address is set to 0, it is the broadcast
communication address, and all the slaves on the
MODBUS bus will accept this frame, but the slave
never responds.
Local communication address is unique in the
communication network, which is the basis for
point-to-point communication between the upper
computer and the inverter.
Note: The slave address cannot be set to 0.
This parameter is used to set the data transmission
speed between upper computer and the inverter.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
-185-
Chapter 6
Default Modi
value fy
0
○
2.00
○
0
○
0.5s
○
0.0
○
0
○
1
○
4
○
