INVT Goodrive350 Series Operation Manual page 89

Goodrive350 series high-performance multi-function inverter
Function
code
Corresponding setting of
P05.42 upper limit frequency of
HDIA frequency input filter
P05.43
HDIB high-speed pulse input
P05.44
Lower limit frequency of
P05.45
Corresponding setting of
P05.46
lower limit frequency of HDIB
Upper limit frequency of
P05.47
Corresponding setting of
P05.48 upper limit frequency of
HDIB frequency input filter
P05.49
P05.50 AI1 input signal type
5.5.10 Analog output
GD350 series inverter carries one analog output terminal (0–10V/0–20mA) and one high-speed pulse
output terminal. Analog output signals can be filtered separately, and the proportional relation can be
adjusted by setting the max. value, min. value, and the percentage of their corresponding output.
Analog output signal can output motor speed, output frequency, output current, motor torque and
motor power at a certain proportion.
Name
HDIA
time
function selection
HDIB
HDIB
HDIB
time
Detailed parameter description
-100.0%–100.0%
0.000s–10.000s
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIA
0.000 KHz – P05.47
-100.0%–100.0%
P05.45 –50.000KHz
-100.0%–100.0%
0.000s–10.000s
0–1
0: Voltage type
1: Current type
-84-
Chapter 5
Default
value
100.0%
0.030s
0
0.000KHz
0.0%
50.000KHz
100.0%
0.030s
0
