P08.02 Acceleration time 3
P08.03 Declaration time 3
P08.04 Acceleration time 4
P08.05 Declaration time 4
Switching frequency of
P08.19
acceleration/deceleration time
Reference frequency of
P08.21
acceleration/deceleration time
P08.28 Automatic fault reset times
Automatic fault reset time
P08.29
5.5.8 Frequency setup
GD350 series inverter supports multiple kinds of frequency reference modes, which can be
categorized into two types: main reference channel and auxiliary reference channel.
There are two main reference channels, namely frequency reference channel A and frequency
reference channel B. These two channels support simple arithmetical operation between each other,
and they can be switched dynamically by setting multi-function terminals.
There is one input mode for auxiliary reference channel, namely terminal UP/DOWN switch input. By
setting function codes, users can enable the corresponding reference mode and the impact made on
the inverter frequency reference by this reference mode .
The actual reference of inverter is comprised of the main reference channel and auxiliary reference
channel.
Name
interval
Detailed parameter description
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.00–P00.03 (max. output frequency)
0.00Hz: No switch over
If the running frequency is larger than
P08.19, switch to acceleration
/deceleration time 2
0: Max. output frequency
1: Set frequency
2: 100Hz
Note: Valid for straight-line
acceleration/deceleration only
0–10
0.1–3600.0s
-78-
Chapter 5
Default
value
Depend
on model
Depend
on model
Depend
on model
Depend
on model
0
0
0
1.0s
