INVT Goodrive350 Series Operation Manual page 222

Goodrive350 series high-performance multi-function inverter
Function
Name
code
switch-off delay
AO2 output
P26.35
selection
AO3 output
P26.36
selection
Reserved
P26.37
variables
Lower limit of
P26.38
AO2 output
Corresponding
P26.39 AO2 output of
lower limit
Upper limit of
P26.40
AO2 output
Corresponding
P26.41 AO2 output of
upper limit
AO2 output filter
P26.42
time
Lower limit of
P26.43
AO3 output
Corresponding
P26.44 AO3 output of
lower limit
Upper limit of
P26.45
AO3 output
Corresponding
P26.46 AO3 output of
upper limit
AO3 output filter
P26.47
time
P26.48– Reserved
P26.52 variables
P28 group Master/slave control functions
P28.00– Reserved
P28.39 variables
P90 group Customized function group 1
Detailed parameter description
The same with P06.14
Above function codes define the relation between
output value and analog output. When the output
value exceeds the set max./min. output range, the
upper/low limit of output will be adopted during
calculation.
When analog output is current output, 1mA
corresponds to 0.5V voltage. In different
applications, 100% of output value corresponds to
different analog outputs.
10V (20mA)
AO
0.0%
Setting range of P26.38: -100.0%–P26.40
Setting range of P26.39: 0.00V–10.00V
Setting range of P26.40: P26.38–100.0%
Setting range of P26.41: 0.00V–10.00V
Setting range of P26.42: 0.000s–10.000s
Setting range of P26.43: -100.0%–P26.45
Setting range of P26.44: 0.00V–10.00V
Setting range of P26.45: P26.43–100.0%
Setting range of P26.46: 0.00V–10.00V
Setting range of P26.47: 0.000s–10.000s
0–65535
0–65535
-217-
Default
value
0
0
0
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
100.0%
0.00V
100.0%
10.00V
0.000s
0
0
