INVT Goodrive350 Series Operation Manual page 217

Goodrive350 series high-performance multi-function inverter
Function
Name
code
P25 group Extension I/O card input functions
HDI3 input type
P25.00
selection
S5 terminal
P25.01
function
S6 terminal
P25.02
function
S7 terminal
P25.03
function
S8 terminal
P25.04
function
S9 terminal
P25.05
function
S10 terminal
P25.06
function
HDI3 terminal
P25.07
function
Input terminal
P25.08 polarity of
extension card
Virtual terminal
P25.09 setup of
extension card
HDI3 terminal
P25.10
switch-on delay These function codes define corresponding delay of
HDI3 terminal
P25.11
switch-off delay
S5 terminal
P25.12
switch-on delay
S5 switch-off
P25.13
delay
S6 terminal
P25.14
switch-on delay
Detailed parameter description
0: HDI3 is high-speed pulse input
1: HDI3 is digital input
The same with P05 group
0x00–0x7F
0x000–0x7F (0: disable, 1: enable)
BIT0: S5 virtual terminal
BIT1: S6 virtual terminal
BIT2: S7 virtual terminal
BIT3: S8 virtual terminal
BIT4: S9 virtual terminal
BIT5: S10 virtual terminal
BIT6: HDI3 virtual terminal
the programmable input terminals during level
variation from switch-on to switch-off .
Si electrical level
Si valid invalid
Switcn-on
delay
Setting range: 0.000–50.000s
-212-
valid invalid
Switcn-off
delay
Chapter 6
Default Modi
value fy
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0x00
○
0x00
◎
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
