Goodrive350 series high-performance multi-function inverter
Function
Name
code
V/F frequency
P04.03
point 1 of motor 1
V/F voltage point
P04.04
1 of motor 1
V/F frequency
P04.05
point 2 of motor 1
V/F voltage point
P04.06
2 of motor 1
V/F frequency
P04.07
point 3 of motor 1
V/F voltage point
P04.08
3 of motor 1
Detailed parameter description
however, if the torque boost is too large, the motor
will run at over-excitation, which will cause increased
output current and motor heat-up, thus degrading the
efficiency.
When torque boost is set to 0.0%, the inverter is
automatic torque boost.
Torque boost cut-off threshold: Below this frequency
threshold, the torque boost is valid, exceeding this
threshold will nullify torque boost.
Output voltage
v
b
v
boost
Setting range of P04.01: 0.0%: (automatic) 0.1%–
10.0%
Setting range of P04.02: 0.0%–50.0%
When P04.00 =1 (multi-point V/F curve), users can
set V/F curve via P04.03–P04.08.
V/F curve is usually set according to the
characteristics of motor load.
Note: V1<V2<V3, f1<f2<f3. If low-frequency voltage
is set too high, motor overheat or burnt-down may
occur, and overcurrent stall or overcurrent protection
may occur to the inverter.
Output voltage
100.0%
V
b
V3
V2
V1
Setting range of P04.03: 0.00Hz–P04.05
Setting range of P04.04: 0.0%–110.0% (rated
voltage of motor 1)
Setting range of P04.05: P04.03–P04.07
Setting range of P04.06: 0.0%–110.0% (rated
-140-
Output
frequency
f f
Cut-off
Output
frequency(Hz)
f1 f2 f3 f
b
Chapter 6
Default Modi
value fy
0.00Hz
○
00.0%
○
0.00Hz
○
0.0%
○
0.00Hz
○
00.0%
○
