Goodrive350 series high-performance multi-function inverter
To ensure safety, you can configure an electromagnetic contactor on the input side to control the
switch-on and switch-off of the main circuit power, so that the input power supply of the inverter can
be effectively cut off when a system fault occurs.
D.5.1 Breakers and electromagnetic contactors for AC 3PH 380V (-15%)–440V (+10%)
Inverter model
GD350-1R5G-4
GD350-2R2G-4
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110G-4
GD350-132G-4
GD350-160G-4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-350G-4
GD350-400G-4
GD350-500G-4
Note: The accessory specifications described in the preceding table are ideal values. You can select
Breaker
Fuse (A
(A)
1 16
17.4 16
30 25
45 25
60 40
78 63
105 63
114 100
138 100
186 125
228 160
270 200
315 200
420 250
480 315
630 400
720 400
870 630
1110 630
1110 630
1230 800
1380 800
1500 1000
1740 1200
1860 1280
2010 1380
2505 1720
-319-
Appendix D
Rated current of the
contactor (A)
10
10
16
16
25
32
50
63
80
95
120
135
170
230
280
315
380
450
580
580
630
700
780
900
960
1035
1290
