INVT Goodrive350 Series Operation Manual page 170

Goodrive350 series high-performance multi-function inverter
Function
Name
code
Detection value
P08.36 for frequency
arrival
Enable/disable
energy-
P08.37
consumption
brake
Energy-
consumption
P08.38
brake threshold
voltage
Detailed parameter description
Output frequency f
FDT level
Y1,
RO1, RO2
Setting range of P08.32: 0.00Hz–P00.03 (max.
output frequency)
Setting range of P08.33: 0.0–100.0% (FDT1 level)
Setting range of P08.34: 0.00Hz–P00.03 (max.
output frequency)
Setting range of P08.35: 0.0–100.0% (FDT2 level)
When the output frequency is within the positive
/negative detection range of the set frequency, the
multi-function digital output terminal outputs
"frequency arrival" signal as shown below.
Output frequency
Set
frequency
Y,
RO1, RO2
Setting range: 0.00Hz–P00.03 (max. output
frequency)
0: Disable energy-consumption
1: Enable energy-consumption
Set the starting bus voltage of energy-consumption
brake, adjust this value properly can brake the load
effectively. The default value will change with the
change of voltage class.
Setting range: 200.0–2000.0V
-165-
FDT lag
Time t
Time t
Detection amplitude
Time t
Time t
Chapter 6
Default Modi
value fy
0.00Hz
○
1
○
220V
voltage:
380.0V;
○
380V
voltage:
